N2K bearings are being manufactured in China as per our customer’s requirement, all bearings are ISO standard with outer & inner rings are of GCr15 steel and steel balls in ball bearings are of high chrome high carbon G5.
BALL BEARING
6000 to 6028 – in Plain, ZZ & 2RS shield
6200 to 6228 – in Plain, ZZ & 2RS shield
6300 to 6028 – in Plain, ZZ & 2RS shield
6400 to 6416
RS shield is of Black colour. Standard quality bearings are with normal radial clearance but C3 clearance can be provided on request. Noise level is Z2
outer & inner rings are of GCr15 steel and steel balls in ball bearings are of high chrome high carbon G5
SELF ALIGNING BALL BEARING
1205 to 1220 in straight and K taper bore
1304 to 1317 in straight and K taper bore
All bearings are with Steel cage
2201 to 2218 in straight and K taper bore
2304 to 2318 in straight and K taper bore
All bearings are with 2 piece steel cage
outer & inner rings are of GCr15 steel and steel balls in ball bearings are of high chrome high carbon G5
TAPER ROLLER BEARING
30207 to 30230
30307 to 30322
31309 to 31319
32207 to 32228
32310 to 32322
outer & inner rings are of GCr15 steel and rollers are of high chrome high carbon
SPHERICAL ROLLER BEARING
22211MBW33C3 to 22244MBW33C3
22211KMBW33C3 to 22244KMBW33C3
22312MBW33C3 to 22344MBW33C3
22312KMBW33C3 to 22344KMBW33C3
23060CA to 23080CA
23138CA to 23168CA
Cages are all of Machined Brass cage: MB type is two piece cage with a flange on inner ring and CA type is single cage without middle flange.
Outer & Inner rings are of GCr15 steel, and hardness of rings rollers is between 58 to 62. Radial clearance is C3 but for tough conditions we recommend C4 clearance. W33 is generally produced on outer ring of MB type bearing for lubrication groove with 3 holes in outer rings
PILLOW BLOCK BEARING
UC 204 to UC 218 IN MM AND INCH SIZE
UK 206 TO UK 215
UCP 204 to UCP 218 IN MM AND INCH SIZE
UCF 205 to UCF 218 IN MM AND INCH SIZE
UCT 205 TO UCT 218
UCFL 205 TO UCFL 212
UC bearings are with normal radial clearance. Outer & inner rings are of GCr15 steel and steel balls in ball bearings are of high chrome high carbon G5. The bearings has two shield on each side, the inner shield is RS and outer of ZZ steel shield.
Pillow Block Housing are made of cast iron with provision for 2 bolts and nipple for lubrication.
ADAPTER SLEEVES WITH LOCK NUTS & WASHERS
H-208 to H-222
H-308 to H-322
H-2308 to H-2336
H-3024 to H3040
H-3122 to H-3140
HE-209 to HE-217
HE-308 to HE-322
HE-2308 to HE-2322
LOCK NUTS
KM-8 to KM-28
LOCK WASHER
MB-0 to MB-40
Tolerance for Adapter sleeves and lock nut washer are as per IS-8656-1977 and material IS/R-113-1969 Standard
PLUMMER BLOCKS
Our Plummer block housing are made in India. Plummer block housing fitted with rolling bearings which are easily replaceable bearing units and require very little maintenance. Most of the bearing housing are horizontally splited, suitable for bearing having tapered bore or cylindrical bore. These housings are made from high grade cast iron IS: 210-1978 / cast steel confirming to IS: 1030.
The cast steel and the spheroidal graphite cast iron housing are generally selected for heavy loads or shook loads applications. Our housing are dimensionally interchangeable and suitable for bearing size of any good quality brand. Plummer blocks are available in S, SN, SNA, SNH, SNL, SD, SDJC, SAF, SDAF, SOFN, SBDS, BND, SDGC, TVN, PDN.
